mmo2007-009-043_b
MULTIFUNCTION GAUGE HEATING
INTENSITY
1. Co lder
2. Warmer
Heating Throttle Lever Switch
Select the desired position to keep
your thumb at a comfortable temper-
ature.
Rave 600 only.
mmo2007-003-003_c
TYPICAL
1. Heated throttle lever switch
2. Hot
3. Warm
4. Off
All other RE-X models.
mmo2008-003-009_d
1. Heated throttle lever switch
2. Warmer
3. Co lder
Heating throttle lever will be in OFF
positionwhentherearenobarsleftin
the display.
NOTE: Bar ga ug e will be displayed
with the activation of the throttle leve r
switch. When releas ed , display will
return to fuel tank level.
mmo2007-009-044_b
MULTIFUNCTION GAUGE HEATING
INTENSITY
1. Co lder
2. Warmer
_____________________
51
