Lynx RaveTM RE 600 E-TEC - Page 94

MODEL
RAVE 800 R POWER TEK/
XTRIM 800R PO WER TE K
DRIVE SYSTEM (cont'd)
Track profile height 38 mm
Deflection 30-35 mm
Track tension
Force
(1)
7.3 kg
Track alignm ent
Equal distance between edges
of track guides and slid er shoes
SUSPENSION
Front suspension
A-FLS
Rave 800 R
Power TEK
36mm H PG clicker T/A
Front shock
Rave Xtrim 800
R Power TEK
36mm HPG T/A
Front suspension max. travel 242 mm
Rave 800 R
Power TEK
PPS-121
Rear suspension
Rave Xtrim 800
R Power TEK
PPS-144
Rave 800 R
Power TEK
46mm H PG clicker T/A
Front arm shock
Rave Xtrim 800
R POwer TEK
36mm HPG T/A
Rave 800 R
Power TEK
46mm HPG-clicker T/A
Rear arm shock
Rave Xtrim 800
R Power TEK
46mm HPG T/A Piggy pag
Rear suspension max. travel 390 mm
ELECTRICAL
Lightning system output
360 Watts @ 6000 RPM
Headlamp bulb HI/LOW beam
2 x 60/55 Watts (H-4)
Taillight bulb 5/21
Type
NGK BR9ECS
(2)
Spark plug
Gap
Not adjustable
(0.80 ± 0.05 mm
Fuse
Refer to FUSE section
