Magtec MT884 - 9 Alarm; Sensor Alarm

Alarm
AHD Hybrid DVR User Manual
34
9 Alarm
Alarm settings include sensor alarm, motion alarm, video loss alarm, other alarm and alarm
out setting.
9.1 Sensor Alarm
Some models may support this function. Operate the following steps to configure sensor based
alarm:
① Go to Main MenuSetupAlarmSensorBasic tab.
② Enable channels by checking the checkboxes beside the desired channels.
③ Set the alarm type according to triggered alarm type. Two options: NO and NC.
④ Click “Apply” button to save the setting.
⑤ Go to Alarm Handling tab. Select hold time.
⑥ Click “Setting” button to pop up a dialog box as shown below.
