Appendix B Calculate Recording Capacity
You can calculate the size of hard disk according to the storage time and AHD Hybrid DVR
recording settings. The formula is as follows in full frame rate condition. Used space per hour
(MB/h) = Bitrate (kbps) ÷ 8 × 3600 ÷ 1024. The below are the details at different settings.
The calculation format is:
Total Recording capacity = Used space per hour (MB/h) (coverage rate of hard disk) ×
recording time (hour) × channel numbers
For instance, one customer sets resolution to 720P, frame rate to 15fps, bitrate to 4M and
enables total 4 channels. He wants the unit to record continuously in a month. Below is the
calculation:
Total Recoding capacity = 225 (mb/h) × 24(hours/day) × 30(days) × 4 (channels) =
648000 (MB) ≈ 633(GB)
Therefore, customers need to install 1 SATA HDD with 1TB to record for one month.
