Mahr umaxum II User Manual

17
Setup Modes - Standard Model
M1
signifies Measurement Direction / Analog Scale Magnification
[S]
M2
signifies Preset Entry Mode
[S]
M12
signifies Limit #1 Tolerance Entry Mode
[S]
M23
signifies Limit #2 Tolerance Entry Mode
[S]
M13
signifies Digital Resolution Selection Mode
[S]
Setup Modes - Advanced Model
M1
signifies Measurement Direction / Analog Scale Magnification
[S]
M2
signifies Preset Entry Mode
[S]
M12
signifies Limit #1 Tolerance Entry Mode
[S]
M23
signifies Limit #2 Tolerance Entry Mode
[S]
M13
signifies Digital Resolution Selection Mode
[S]
M3 signifies Multiplier Mode
M1 X1 signifies Difference mode operation
M2 X1 signifies Dynamic mode operation
M3 X1 signifies Data output operation
M123 signifies Calibration Mode
