16
5.0 Setup Mode
All µMaxµm II style indicators are covered in this manual.
NOTE: If the unit is configured with a lockout feature, a prompt to enter a 4 digit numeric
password will appear. Only the Setup and Calibration modes are accessible by entering the
correct password. All other locked features are not accessible.
Entering the setup modes is accomplished by pressing and holding the M/OFF button and
then press and release the inch/mm button. The M1 icon will be displayed. Then press
and release the M/OFF button until the desired Mx icon is displayed in the lower left cor-
ner of the LCD display.
The µMaxum
II sequences through several setup modes identified on the display by M1,
M2, M12, M23, M13, (M3, M1X1, M2X1, M3X1) and M123 icons. The icon’s are located
on the lower part of the display to identify the selected setup mode.
