8
Range Signal
Notifies an “off-scale” condition when the digital range is exceeded. The digital display will
turn off and the analog left or right arrow will be left on.
2.2 Control Features
Makes use of three push buttons (inch/mm, M/OFF, ZERO/ON).
NOTE: If the unit is configured with a lockout feature, it will prompt the operator for a fac-
tory set password.
inch/mm (Hold)
Normal Operation [S]: Allows the selection of inch or metric display any time a reading is
present.
Dynamic Operation : Toggles between hold and resume of the displayed reading.
M/OFF (Data)
Normal Operation [S]: Used to turn the unit “OFF”, send data, and for entering Setup
Mode.The M/OFF button must be held down for a minimum of 3 seconds to turn the unit
“OFF”. A quick press sends the displayed reading to the Output Port.
Dynamic Operation: Cycles through Difference Mode Data Collection.
ZERO/ON (Reset)
Normal Operation [S]: This button is used to turn the unit “ON”. It is also used to electroni-
cally set the analog display to its mid-point and set the digital display to zero or a preset
value (if used).
Dynamic Operation: Used to reset and restart a min, max, TIR Dynamic Measurement.
