36
No icon indicates that the bargraph is
disabled. Analog bargraph range and graduation
resolution are shown in the table below:
Figur
e 27 -
Analog Magnification T
able
Display Icon
± Full Scale
Grad Value
(in/mm)
(in/mm)
no icon
X1
0.040 / 1.00
0.0020 / 0.050
X5
0.020 / 0.20
0.0010 / 0.010
X10
0.010 / 0.10
0.0005 / 0.005
X50
0.002 / 0.02
0.0001 / 0.001
uMaxum
II
bar graph disabled
35
37
Table of Contents
Table of Contents
4
Precautions and General Information
7
Product Features
7
Hardware Display
7
Control Features
8
Setup Features
9
Special Options Available in ΜmaxµM II Indicators
11
Inspection
14
Mounting Gage for Setup
15
Setup Mode
16
Changing Measurement Direction (M1) [S]
18
Changing Analog Magnification (M1) [S]
19
Entering a Preset (M2) [S]
20
Entering Tolerances (M12, M23) [S]
22
Changing Digital Resolution (M13) [S]
24
Multiplier Entry (M3)
25
Changing Operation to Difference Mode (M1 X1)
26
Changing to Dynamic Max, Min or TIR Operation (M2 X1)
28
Changing Dynamic Hold Operation (M2 X1)
29
Changing Data Output Configuration (M3 X1)
30
Calibration Mode (M123) [S]
32
User Operation
35
Measurement Direction [S]
35
Analog Magnification [S]
35
Preset [S]
37
Tolerances [S]
37
Analog Bargraph Operation [S]
38
Digital GO/NOGO Operation [S]
38
Resolution [S]
39
Multiplier
39
Difference Mode
40
Dynamic Max, Min, TIR
42
Hold Function
43
Display Messages
43
Battery Low Signal
43
Lockout
44
Maintenance
45
Spindle Maintenance
45
Changing the Battery
45
Data Output
48
Parts and Service
54
Replacement Parts
55
ΜmaxµMII
58
Accessories
58
Specifications - ΜmaxµM II
60
Special Options
61
Program Codes
61
Lockout Password
62
