50
USB Data Cable 200
0 SB
Figur
e 39 -
USB Data Cable 2000 SB
Virtual COM-Interface Driver:
The Driver emulates for every connected ca
ble an
additional virtual
COM-Port. The appli-
cation software co
mmunicates to the instrument in exactly the same man
ner as a normal
hardware COM-Port.
NOTE:
When Used with Marco
m Softwar
e:
Make sur
e serial number featur
e is off. Pr
es
et value should be six numeric digits or less.
2000 USB
Data Cable
Order No. 4346023
