Mahr umaxum II User Manual

56
8.1.1 µMaxµm II
Integral Model
Figure 43 - Integral Model
Perpendicular Model
Figure 44 - Perpendicular Model
.250”
6.3mm”
EBK-1010
270°
2.30”
58mm
1.58”
40mm
.750”
.4619mm
“A”“B”“C”
A
.46”/11.7mm
1.50”/38mm
B
.95”/24.1mm
2.25”/57.2mm
C
2.11”/53.6mm
3.41”/86.6mm
Display
Rotates
9
4
5
6
10
7
8
3.75”
9.5mm
1.339”
34mm
0.625”
16mm
2.30”
58mm
“A”
“B”
.46”/11.7mm
1.50”/38mm
A
.95”/24.1mm
2.25”/57.2mm
B
