59
Figure 46 - Indicator Back
NOTE: Exercise care when installing Indicator Back accessories. make sure gasket seals are
in good condition and properly oriented. DO NOT OVERTIGHTEN SCREWS.
9
10
Lug
Back
Standard Flat
Back
