A
02.04 11
CHAPTER
PAGEISSUE
CHASSIS
ENGLISH
SECTION 2
Getting to know your motorbike
SECTION 2
A - CHASSIS
ENDURO SUPERMOTARD
Transmission:
Primary reduction system helical gears
Primary reduction ratio z71 / z20 (3,55)
Secondary reduction system chain drive
Secondary reduction ratio z50 / z11 (4,54) z48 / z11 (4,36)
Transmission type mechanical, 6-speed
Type left foot
Gear ratio:
1
st
speed z12 / z36 1:3
2
nd
speed z16 / z33 1:2.06
3
rd
speed z19 / z29 1:1.52
4
th
speed z22 / z27 1:1.23
5
th
speed z24 / z25 1:1.04
6
th
speed z25 / z24 1:0.96
Tires:
Type with tube
Front 80/90-21 48P 100/80-17 52S
Rear 110/80-18 58P 130/70-17 62S
Manufacturer PIRELLI
Tire pressure (ambient temperature):
Front 0 ~ 90 kg 2.0 bar
Rear 0 ~ 90 kg 2.2 bar
Front 90 kg ~ max. load 2.0 bar
Rear 90 kg ~ max. load 2.2 bar
Brakes:
Front hydraulic disk type Ø240 mm hydraulic disk type Ø259 mm
Calipers with two pistons
Operation right hand operation
Rear hydraulic disk type Ø218 mm hydraulic disk type Ø218 mm
Calipers with two pistons
Operation right foot operation
Suspensions:
Front telescopic fork
Max. stroke 190 ± 2 mm
Rear swingarm
Max. stroke 44 ± 2
Electrical equipment:
Ignition system C.D.I. control unit.
Generator, rated power FLYWHEEL MAGNETO, 95W
Type of battery calling for maintenance
Battery capacity 12 4 Ah
Fuel sensor electrical floating probe
Horn 12 V DC
Lights
Headlight 12V 35/35 W
Tail-light 12V P21/5 W
Indicators front/rear 12V 10W x 4
Indicator lights LED
Parking light 12V 4W (Switzerland version only)
Low beam indicator light 12V 1,2W (Switzerland version only)
Number plate light 12V 5W (Switzerland version only)
Model:
