Malaguti XTM 50 - DISASSEMBLY: FRONT BRAKE CALIPERS AND SENSOR; FRONT BRAKE CALIPERS (MOTARD;ENDURO); SPEEDOMETER SENSOR REMOVAL

A
02.04 35
CHAPTER
PAGEISSUE
CHASSIS
ENGLISH
SECTION 2
Disassembly XTM - XSM
SECTION 3
A - CHASSIS
F.43A
F.43B
F.44
V
SPEEDOMETER SENSOR
Loosen the screw (V - F.44) and remove the sen-
sor; release the cable from the U-bolts and detach
the connector under the headlight.
Caution!!! When refitting, pay attention
to the shim washer between the sen-
sor and the fork.
REMOVING THE FRONT BRAKE CALIPERS
(ENDURO model).
.
REMOVING THE FRONT BRAKE CALIPERS
(MOTARD model).
