Malaguti XTM 50 - Main Components

A
02.04 13
CHAPTER
PAGEISSUE
CHASSIS
ENGLISH
SECTION 2
Getting to know your motorbike
SECTION 2
A - CHASSIS
11
6
12
10
7
8
9
1
2
3
5
4
12
F.3i
F.4i
13
MAIN COMPONENTS
(Left hand side)
1. Headlight
2. Oil tank
3. Battery
4. Air filter
5. Shift pedal
MAIN COMPONENTS
(Right hand side)
6. Radiator
7. Owner’s tool bag
8. Fuse
9. Fuel tank cap
10. Rear brake pedal
11. Passenger foot rests
12. Passenger holder
13. Number plate light +
number plate holder
(SWITZERLAND only)
