A
02.04 15
CHAPTER
PAGEISSUE
CHASSIS
ENGLISH
SECTION 2
Getting to know your motorbike
SECTION 2
A - CHASSIS
1
2
3
5
6
4
F.7i
F.8i
7
(*)
SIDE STAND
Make sure the sidestand is correctly fitted and that it moves correctly; check
the spring holding the sidestand in place on a regular basis.
DISPLAY
1- Turn indicator light
This light blinks when the turn indicator is pushed
towards left or towards right.
2- Low beam indicator light
This light comes on when the low beam of the head-
light is switched on.
3- Fuel level warning light
This light comes on when the fuel level is low (re-
serve).
Fill the fuel tank.
4- Coolant temperature warning light
This light comes on when the temperature of the coolant is too high.
When this light comes on, stop the engine at once.
5- Neutral indicator light “N”
This light comes on when the transmission is in neutral position.
6- Oil level warning light
This warning light comes on when the oil level is low.
7 (*) - Low beam indicator light
SWITZERLAND version only.
This indicator comes on when the low beam headlight is operated.
KEYS
The vehicle is supplied with two keys featuring a code number, which have the following functions:
• Providing the ignition contact
• Turning the lights on
• Locking the steering system.
STEERING LOCK
Locking: turn the handlebar all the way to the right or left, push the key in and turn it counter-clockwise.
Disengaging: turn the key clockwise.
