A
10 02.04
CHAPTER
PAGE ISSUE
CHASSIS
ENGLISH
SECTION 2
Getting to know your motorbike
SECTION 2
A - CHASSIS
SPECIFICATIONS
ENDURO SUPERMOTARD
Dimensions:
Length 2050 mm 2000 mm
Width 850 mm
Height 1160 mm 1115 mm
Wheel base 1350 mm ± 20
Seat height 910 mm 880 mm
Minimum ground clearance 345 mm 315 mm
Minimum turning radius 2320 mm 2240 mm
Front wheel stroke 190 mm
Rear wheel stroke 220 mm
Weight:
Kerb weight 104 kg
Maximum load 160 kg
Engine:
Type 2-stroke, liquid-cooled
Cylinder arrangement single-cylinder, vertical
Displacement 49 cm
3
Bore x stroke 40.3 x 39 mm
Compression ratio 12:1 ± 0.5
Starting system Kickstarter
Lubricating system separate lubrication
Type of oil:
Engine oil semi-synthetic oil, according to API TC TS C3 standards
Total amount 1.1 L
Transmission oil SAE 10W30 type SE
Total amount 0.82 L
Fuel:
Type RON 91 premium grade unleaded petrol
Fuel tank capacity 6.5 L
Reserve amount 1.8 L
Carburettor:
Type PHBN 16
Manufacturer DELL’ORTO
Chassis:
Chassis welded steel tubular bar.
Caster angle 28°
Spark plug:
Type BR9ES
Manufacturer NGK
Electrode gap 0.6 ~ 0.7 mm
Clutch mechanical, multiple disc, oil-bath type
Air filter sponge, 45ppi
Cooling system
Type water-cooled
Antifreeze-water mixture ratio 1:1
Total amount 0.55 L
Model:
