2 - 71
15 - MOTOR "ECO STOP"
This function allows supporting the I.C. engine stop to limit consumption. This function is possible if all following conditions
are met within a time set by the operator.
•
Rotary I.C. engine.
• Speed of the I.C. engine lower than 1000 rpm.
• No driver present.
• No forced travel in progress.
• No "Parked telehandler" exhaust particulate filter regeneration.
• Parking brake engaged.
• I.C. engine temperature greater than 40 °C.
OPERATION
- Briefly press button
.
• Activation/deactivation of the function.
- Long-press the button
.
• Select the time between 30 seconds and 20 minutes and confirm.
- The visual indication (lights, warnings) of the telehandler remains operating after the motor is stopped.
- Disengage the electrical contact using the front key switch before restarting the telehandler.
t
IMPORTANT
t
The "Eco STOP" function does not replace the stop of the telehandler, the telehandler must be stopped at the end of the operating cycle or the day (e 1 - SAFETY
INSTRUCTIONS AND REGULATIONS: INSTRUCTIONS TO THE OPERATOR: DRIVING INSTRUCTIONS UNLADEN AND LADEN: G - STOPPING THE TELEHANDLER).
16 - TRAILER BRAKE TEST BUTTON
This test is used to check whether the parking brake system allows keeping the telehandler and trailer stationary on an upward
or downward slope even without braked trailer.
OPERATION:
- stop the telehandler,
- press the service brake pedal,
- engage the parking brake of the telehandler pulling the lever fully,
- release the service brake pedal,
- press and keep pressed button 1 for 10s to deactivate the trailer brake,
- this allows keeping the telehandler and trailer stationary, preventing them from
slipping or moving forward or backward.
If the test fails, move to a different operating area.
