Manitou MLT 961-145 V PLUS L JD ST4 S1 - DESCRIPTION AND USE OF OPTIONS

2 - 62
DESCRIPTION AND USE OF OPTIONS
1 - BOOM ELECTRICAL FITTING
Enables an electrical function to be used at the head of the boom.
OPERATION
- Set switch 2 to position 2a to enable the fitting, the indicator lights up to show that it is enabled.
2a
2
Summary
1 - BOOM ELECTRICAL FITTING 62
2 - ELECTRICAL ADJUSTMENT OF THE MAIN RIGHT REAR VIEW MIRROR 63
3 - SEMI-AUTOMATIC WHEEL ALIGNMENT 63
4 - EXTERNAL LOSS RETURN 64
5 - EASY ATTACHMENT HYDRAULIC CONNECTION (ECS) 64
6 - FORCED MODE OF THE ATTACHMENT CIRCUIT 65
7 - BOOM SUSPENSION 66
8
- ATTACHMENT HYDRAULIC LOCK 66
9 - BOOM HEAD SOLENOID VALVE 67
10 - BOOM HEAD SOLENOID VALVE + LOCKING HYDRAULIC ATTACHMENT 68
11 - FOR SINGLE-ACTING REAR HYDRAULIC CONTROL FITTING 69
12 - DUAL-ACTING REAR HYDRAULIC CONTROL FITTING 69
13 - "INTELLIGENT HYDRAULICS" 70
14 - COMFORT STEERING SYSTEM" 70
15
- MOTOR "ECO STOP" 71
16
- TRAILER BRAKE TEST BUTTON 71
17 - ANGULAR SECTOR ON BOOM 72
18 - WINDSCREEN GRILLE 72
