17 - ANGULAR SECTOR ON BOOM
The angular sector displays the boom angle, and thus improves the reading of the load charts.
18 - WINDSCREEN GRILLE
DESCRIPTION
The windscreen grille provides additional protection for the operator from any external
elements spattered on the windscreen.
This grille must be removable from inside the cab to enable an emergency exit.
EMERGENCY EXIT
- After breaking the windscreen with the emergency hammer, push (with force) on
the grille at A to remove it.
A
