Manitou MLT 961-145 V PLUS L JD ST4 S1 User Manual

2 - 51
29
30
28
31
31 - DOOR OPEN LEVER
32 - DOOR CLOSE HANDLE
33 - WINDOW REGULATOR SWITCH
34 - SIDE STORAGE SPACE
35 - CEILING LIGHT
36
- HANDLE FOR REAR WINDOW OPENING
EMERGENCY EXIT
- Use the rear screen as emergency exit if it is not possible to exit from the cab door.
37 - HANDLE FOR REAR WINDOW CLOSING
38 - STEERING WHEEL ADJUSTMENT KNOB
This handle enables the angle and height of the steering wheel to be adjusted.
- Pull the knob backwards.
- Adjust the steering wheel to the desired position.
- Push the knob back to lock the steering wheel in position.
30 - LEVEL INDICATOR
Enables the operator to check that the telehandler is in the horizontal position.
B
