Manitou MLT 961-145 V PLUS L JD ST4 S1 User Manual

2 - 14
TECHNICAL FEATURES
I.C. ENGINE
Engine JOHN DEERE St.4 (Tier IV)
- Type 4045PWL-104 kW
- Fuel Diesel
- Number of cylinders 4 in-line
- Intake Turbocharged
- Injection system Direct
- Firing order 1.3.4.2
- Displacement cm
3
- L 4500 - 4.5
- Bore and stroke mm - in 106 x 127 - 4.17 x 5
- Compression ratio 17
- Nominal speed at full load rpm 2200
- Idle speed when unladen rpm 850
- Maximum speed when unladen rpm 2360
- ISO 3046 Power HP - kW 140 - 104
- SAE J 1995 Power HP - kW 140 - 104
- ISO 3046 max torque Nm - kgf 534 - 54.45 @ 1500 rpm
- After-treatment type DOC/SCR
- ISO 5011 gravimetric efficiency % 99.9
Cooling system
- Coolant circuit Fluid
- Hydraulic oil cooling circuit Hydraulic cooling
- Air cooling circuit Air intake
- Ventilation system Electrohydraulic
- Fan motor type Hydraulic
- Fan speed
rpm
2550
- Number of fan blades 5
- Fan diameter
mm - in
660 - 25.98
TRANSMISSION
Hydrostatic pump
- Type Variable displacement pistons.
- Displacement cm
3
- L 85 - 0,085
- Max flow rate l/min. 280
- Operating pressure bar - psi 450 - 6526.71
Hydrostatic motor (1)
- Type
Variable volume
- Capacity min./max. cm
3
/rev 0 to 115
Hydrostatic motor (2)
- Type
Variable volume
- Capacity min./max. cm
3
/rev 20 to 60
Gearbox
- Type Mechanical with hydraulic drive
- Number of forward speeds 1
- Number of reverse speeds 1
Speed inverter Electromagnetic
Front axle
- Differential Without block
Rear axle
- Differential Without block
Driving wheels 4 permanent driving wheels
Standard front/rear tyres
- Type ALLIANCE
- Size
500/70 - R24 AGRO-IND RADIAL R-4 (580)
- Pressure bar - psi 4.4 - 63.81
Optional front/rear tyres
- Type MICHELIN
- Size
500/70 - R24 IND TL 164A8/B XMCL
- Pressure bar - psi 4.4 - 63.81
Optional front/rear tyres
- Type TRELLEBORG
- Size
500/70 - R24 164A8/164B TH 400
- Pressure bar - psi 4.4 - 63.81
Optional front/rear tyres
- Type MICHELIN
- Size
500/70 - R24 164A8/164B IND TL BIBLOAD
- Pressure bar - psi 4.4 - 63.81
649100 EN-US-AU (20/05/2019) MLT 961-145 V PLUS L JD ST4 S1
