Manitou MLT 961-145 V PLUS L JD ST4 S1 User Manual

2 - 16
Maximum operating pressure bar - psi 280 - 4061.06
- Lifting circuit l/min bar 190 - 145 280 - 4061
- Telescopic arm circuit l/min bar 190 - 145 250 - 280/3625.9 - 4061
- Tilting circuit l/min bar 190 - 190 220 - 290/31.90.8 - 4206
- Optional circuit l/min bar 120-120 280 - 4061
- Steering circuit l/min bar 180 175 - 2538.16
- Brakes circuit bar - psi 25÷ 40 - 362.59 ÷ 580.15
HYDRAULIC MOVEMENTS
Signalling device and longitudinal stability limiter Electronic
Lifting motions
- Unladen lifting s 13.3
- Laden lifting s
-
- Unladen lowering s 7.2
- Laden lowering s
-
Telescopic movements
- Unladen extending s 9.5
- Laden extending s
-
- Unladen retracting s 6.1
- Laden retracting s
-
Tilting movements
- reverse unladen s 3.8
- forward unladen s 4.3
SPECIFICATION AND WEIGHT
Speed of shifting of the telehandler in standard configuration on flat
ground (except specific conditions)
Maximum speed 40 - 24.85
- forward travel unladen km/h - mph 40 - 24.85
- forward travel with rated load km/h - mph 5 - 3.10
- reverse unladen km/h - mph 40 - 24.85
- reverse with rated load km/h - mph 5 - 3.10
Standard attachment mm - in 1200x200x60 - 47.24x7.87x2.36
- Weight with forks kg - lb 200 - 440.92
- Weight of forks (each) kg - lb 78 - 171.96
Rated capacity with standard attachment kg - lb 6000 - 13227.73
Capacity at maximum height with standard attachment
(with tyre
MICHELIN 500/70 - R24 164A8/164B IND TL BIBLOAD)
kg - lb 5000 - 11023.1
Capacity at maximum reach with standard attachment kg - lb 1400 - 11023.1
Distance from centre of gravity of the load to fork base mm - in 600 - 23.62
Standard lifting height m - ft 8.995 - 29.51
Lifting height at maximum capacity
(with tyre
MICHELIN 500/70 - R24 164A8/164B IND TL BIBLOAD)
m - ft 7.660 - 25.13
Extension at maximum reach m - ft 1.7 - 5.57
Telehandler weight with standard attachment
- Unladen kg - lb 11800 - 26014.52
- With nominal load kg - lb -
Weight per axle with standard attachment (transport position)
- front unladen kg - lb 4800 - 10582.18
- Rear unladen kg - lb 7000 - 15432.36
- Front with rated load kg - lb 15700 - 34612.53
- Rear with rated load kg - lb 2100 - 4629.70
Maximum load per wheel daN - kgf 8335.65 - 8500
Tractive force on the tow hook
- Traction force (drawbar) daN - kgf 10000 - 10197
Extraction force with bucket
(compliant with ISO 8313)
CBR 1500 daN - kgf 7300 - 7443.92
CBA 4000 daN - kgf 4370 - 4456.15
Gradeability that can be overcome
- Unloaded
% -
- Loaded % 45
649100 EN-US-AU (20/05/2019) MLT 961-145 V PLUS L JD ST4 S1
