VISIBILITY
Our telehandlers conform to European standard EN15830 with regard to operator visibility.
- Follow the instructions for optimizing operator visibility of the immediate vicinity (e: 1 - OPERATING AND SAFETY
INSTRUCTIONS: INSTRUCTIONS TO THE OPERATOR: DRIVING INSTRUCTIONS UNLADEN AND LADEN: D - VISIBILITY).
DESCRIPTION AND ADJUSTMENT OF REAR-VIEW MIRRORS
1 - LEFT REAR-VIEW MIRROR
2 - MAIN RIGHT REAR-VIEW MIRROR
3 - CENTRAL RIGHT REAR-VIEW MIRROR
4 - UPPER RIGHT REAR-VIEW MIRROR
5 - REAR REAR-VIEW MIRROR
- Place the telehandler on level ground with the I.C. engine
stopped, and the telescopic boom retracted and lowered as
far as possible.
- Note the position of the reference points
in the
illustrations, to e and correctly adjust the rear-view mirrors.
1
2
3
4
5
1
2
5
4
3
1
5
3
2
4
e
e
e
e
e
