Grove Published 3-23-2020, Control # 654-04 4-87
GRT655/655L OPERATOR MANUAL OPERATING PROCEDURES
4
1. Using the Jog Dial or Arrow Buttons on the Navigation
Control Pad, select the controller function icon that is to
be adjusted (icon will turn orange).
2. Press the Jog Dial or OK Button on the Navigation
Control Pad to make the controller function icon active
(icon background will turn gray).
3. Using the Jog Dial or the Up/Down Arrow Buttons, select
one of the five possible sensitivity curves (Figure 4-57).
4. Press the Jog Dial or OK Button on the Navigation
Control Pad to accept the new setting.
Select the Reset icon on the Controller Sensitivity function
screen and press the Jog Dial or the OK Button to set the
sensitivity on both controllers and the foot pedal (optional)
back to the factory default settings.
Setting the Controller Function Speed
The Controller Function Speed screen (Figure 4-58) allows
the operator to adjust the crane function speeds relative to
the positions of the controllers and the foot pedal (optional).
Adjustment is made as a percentage of full rated speed.
A setting of 100% results in the crane function moving at full
rated speed relative to the position of the controller or foot
pedal (optional). A setting of 75% results in the crane
function moving at 75% of full rated speeds throughout the
range of the controller or foot pedal.
FIGURE 4-57
Sensitivity Curves 1 through 5
1234 5
Most sensitive Least sensitive
Icon Description
Swing Function Speed icon - not selected
Swing Function Speed icon - selected
Swing Function Speed icon - active
Telescope Function Speed icon - not
selected
Telescope Function Speed icon - selected
FIGURE 4-58
9219
