GRT655/655L OPERATOR MANUAL LUBRICATION AND MAINTENANCE
6
Item
Lube Point
Description
Figure
No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Drive Train
1
Air Filter Figure 6-1 --- ---
Replace filter element
when fault code 5576 or
3341 appears.
Air Filter - Tier 3 Figure 6-1 --- ---
Replace filter element
when air restriction
indicator is in the red zone.
2 Fuel Filter Figure 6-2 --- ---
Change filter every 500
hours or 6 months.
Fuel filter is located
on inside right-hand
side frame rail
behind the engine.
3
Tier 4 Engine
Crankcase
Figure 6-1 F
18 L
(19 qt)
• Check level every 10
hours or daily.
• Drain, fill and replace
filter every 500 hours.
• Through fill cap to
FULL mark on
dipstick.
• Refer to Item 6.
Tier 3 Engine
Crankcase
Figure 6-1 F
18 L
(19 qt)
• Check level every 10
hours or daily.
• Drain, fill and replace
filter every: 500 hours
(0-500 ppm sulfur fuel);
400 hours
(500-5000 ppm sulfur
fuel); 250 hours
(>5000 ppm sulfur fuel).
• Through fill cap to
FULL mark on
dipstick.
• Refer to Item 6.
4
Engine Cooling
System and SCA
Levels
Figure 6-1 C, D
43 L
45.4 qt
• Check coolant level
every 10 hours or daily.
• Check SCA levels
every 500 hours.
• Check coolant for
contamination every
1000 hours.
Fill top tank to
bottom of filler neck.
Run engine through
two (2) thermal
cycles. Check level
and refill as
required.
NOTE: Refer to Service Manual for information regarding SCA levels and contamination limits.
