OPERATING PROCEDURES GRT655/655L OPERATOR MANUAL
4-38 Published 3-23-2020, Control # 654-04
Item Description Item Description
1 Status Area 25 Low Brake Pressure Indicator
2 Alerts Area 26 Crane Fault Indicator
3 Status Bar 27 Low Boom Angle Indicator
4 Active Screen Indicator Area 28 Telescope Lockout Indicator
5 Transmission Temperature Indicator 29 Third Wrap Indicator (Optional)
6 Fuel Level Indicator 30
Diesel Particulate Filter Indicator (Tier 4
only)
7 Battery Voltage Indicator 31
Inhibit Exhaust System Cleaning Indicator
(Tier 4 only)
8 Engine Speed Indicator 32
High Exhaust System Temperature (HEST)
Indicator (Tier 4 only)
9 Engine Coolant Temperature Indicator 33
Cab Not Fully Lowered Indicator
10
Diesel Exhaust Fluid (DEF) Level Indicator
(Tier 4 only))
34
Low Steering System Pressure Indicator (CE
cranes)
11 Direction/Gear Indicator 35 Working Range Limiter (WRL) Indicator
12 Hoist Camera (optional) 36
Working Range Limiter (WRL) Boom Height
Indicator
13 Right-side Camera (optional) 37
Working Range Limiter (WRL) Boom Angle
Indicator
14 Engine Wait-to-Start Indicator 38
Working Range Limiter (WRL) Radius
Indicator
15 Parking Brake Indicator 39
Working Range Limiter (WRL) Swing Angle
Indicator
16 Emergency Stop Indicator 40
Working Range Limiter (WRL) Virtual Walls
Indicator
17 Marker/Position/Side Lights Indicator 41
Diesel Exhaust Fluid (DEF) Level Indicator
(Tier 4 only)
18 Rear Wheels Not Centered Indicator 42 Swing Enable/Disable Indicator
19 Four-Wheel Drive Indicator 43 Telescope Enable/Disable Indicator
20 Differential Lock Indicator (optional) 44 Boom Lift Enable/Disable Indicator
21 -29°C Temperature Indicator 45 Main Hoist Enable/Disable Indicator
22 Engine Stop Indicator 46
Auxiliary Hoist Enable/Disable Indicator
(optional)
23 Engine Warning Indicator 47 Active Screen Indicator
24 Hydraulic Oil Temperature Indicator
