Manitowoc MLC300 - Page 206

Reference Only
POWER TRAIN MLC300 SERVICE/MAINTENANCE MANUAL
7-12
Published 11-22-17, Control # 257-02
View C
Collar Wrench
Item Description
1 Drain Valve
2Vent Cap
3 Cover
4Filter
5 Housing
6 Fuel Inlet Port
7 Fuel Outlet Port
8a Collar Wrench
8b Applying Collar Wrench to Collar
9Collar
10 Label with Black Bar
11 Spring
View B
Housing
View A
FIGURE 7-10
