Manitowoc Published 11-22-17, Control # 257-02 2-9
MLC300 SERVICE/MAINTENANCE MANUAL HYDRAULIC SYSTEM
2
Drums 2, 3, 4, and 6 Motors
Drums 2, 3, 4, and 6 motors (Figure 2-9) are bidirectional,
variable-displacement motors. Motor displacements are
controlled by electronic motor controllers.
Item Description
1 Case Drain Port L1
2 Gauge Port M5
3 System Pressure A
4 Gauge Port MA
5 Gauge Port MB
6 Gauge Port M4
7 System Pressure B
8 Case Drain Port L2
FIGURE 2-9
