SETUP AND INSTALLATION MLC300 OPERATOR MANUAL
4-2
Published 11-20-19, Control # 234-19
ASSEMBLY AND DISASSEMBLY NOTES
The crane, boom, and jib must be assembled and
disassembled by experienced personnel trained in erection
and operation of construction cranes.
Before attempting to assemble, operate, or disassemble the
crane, the experienced personnel shall read and become
thoroughly familiar with the following:
• The instructions in the applicable capacity charts located
in the Capacity Chart Manual or at the end of this
section.
• The safety, assembly and disassembly instructions in
this section.
• The instructions in the Boom and Jib Assembly
Drawings located at the end of this section.
Contact your Manitowoc dealer for assistance if any
procedure is not fully understood.
ASSEMBLY AND DISASSEMBLY AREA
Select an assembly/disassembly area that has a firm, level,
uniformly supporting surface. Make sure the area is large
enough to accommodate the crane and the selected boom
length, movement of trucks with trailers, and movement of an
assist crane.
Set the carbody jack pads on a flat, firm foundation that will
support the load placed on them. See Table 4-1
for loadings.
Table 4-1
Do not set the carbody jack pads in holes, on rocky ground,
or on extremely soft ground.
If necessary, use wood blocking or steel plates under the
carbody jack pads to properly distribute loading. The wood
blocking or steel plates must be:
• Free of defects
• Strong enough to prevent being crushed or bent
• Of sufficient length and width to prevent settling under
load
Contact your Manitowoc dealer for ground bearing
information.
ACCESSING PARTS
Some parts of the crane, boom, and jib cannot be reached
from the ground. Take the necessary precautions to prevent
slipping and/or falling off the crane, live mast, boom, or jib
during assembly disassembly, maintenance, or other work.
Falling from any height could result in serious injury or
death.
WARNING
Moving Parts/Pinch Points!
Avoid death or crushing injury during crane assembly and
disassembly:
• Assembly personnel — take every precaution to
prevent injury when working near moving parts.
• Maintain communication between operator and
assemblers to avoid accidents.
• Do not raise or lower the live mast until all personnel
are off the crane.
• Keep unauthorized personnel well clear of the crane.
Maximum Jack Pad Load on First Stage of each Jack —
60 115 kg (132,530 lb) at 207 bar (3,000 psi)
Jack Pad Diameter — 775 mm (30-1/2 in)
Jack Pad Weight — 45 kg (99 lb)
WARNING
Fall Hazard!
To avoid serious injury, the owner/user shall provide
workers with approved ladders or aerial work platforms to
access those areas of the crane, live mast, and boom that
cannot be reached from the ground or from Manitowoc-
provided steps, ladders, catwalks and platforms.
Adhere to local, state, and federal regulations for handling
personnel and personnel fall protection.
