OPERATING CONTROLS AND PROCEDURES MLC300 OPERATOR MANUAL
3-4
Published 11-20-19, Control # 234-19
SYMBOLS USED ON CONTROL CONSOLES
The following symbols are used on the control consoles to identify the operating controls and their operation.
Table 3-2. Symbol Identification — Control Consoles
Battery, 12 Volt Supply
Cylinders, Mast Assist Arms,
Extend and Retract
Bypass, Crane Limits Drum
Cab Tilt Down Drum, Free Fall
Cab Tilt Up Drum, Lower
Camera
Drum Number (location of number
varies)
Crawlers Drum, Raise
Counterweight, VPC (variable
position counterweight)
Engine or Auxiliary Engine
