152
DSP for CD and DVD-ROM systems
SAA7335
V
SSD7
82 supply digital ground 7
RAMAD7 83 O RAM address bit 7 output
RAMAD8 84 O RAM address bit 8 output
RAMAD9 85 O RAM address bit 9 output
n.c. 86 − not connected, reserved
RAMAD10 87 O RAM address bit 10 output
RAMAD11 88 O RAM address bit 11 output
RAMAD12 89 O RAM address bit 12 output
RAMAD13 90 O RAM address bit 13 output
RAMAD14 91 O RAM address bit 14 output
V
DDD8
92 supply digital supply voltage 8
V
SSD8
93 supply digital ground 8
CRIN 94 I analog crystal input
CROUT 95 O analog crystal output
CFLG 96 O correction statistics output
MEAS1 97 O front-end telemetry output
V
DDD9
98 supply digital supply voltage 9
V
SSD9
99 supply digital ground 9
V
DDA1
100 supply analog supply voltage 1
SYMBOL PIN TYPE DESCRIPTION
