Marantz SA12 - Nuclei Error Codes; Host Decoder Nuclei

20
Script Menu
1. User/Dealer Script
2. Player Script
5. Pink Noise →
6. Sine Generate →
7. Digital Board Version [108]
8. Flash Checksum [100]
9. Flash1 Write Access [101]
10. Flash2 Write Access [102]
11. Flash Write/Read [103]
12. Host SDRAM Write/Read [104]
13. Host SDRAM Write/Read Fast [105]
14. Host DRAM Write/Read [106]
15. Host DRAM Write/Read Fast [107]
16. NVRAM I2C [123]
17. NVRAM Write/Read [122]
Audio Mute Menu
1. Audio Mute On [109]
2. Audio Mute Off [110]
Centre On Stereo Menu
1. Centre-On-Stereo Pin On [113]
2. Centre-On-Stereo Pin Off [114]
Colourbar Menu
1. Colourbar On [120]
2. Colourbar Off [121]
De-Emphasis Menu
1. De-Emphasis On [111]
2. De-Emphasis Off [112]
Pink Noise Menu
1. Pink Noise On [115]
2. Pink Noise On Channel 1 [124]
3. Pink Noise On Channel 2 [125]
4. Pink Noise On Channel 3 [126]
5. Pink Noise On Channel 4 [127]
6. Pink Noise On Channel 5 [128]
7. Pink Noise On Channel 6 [129]
8. Pink Noise Off [116]
Sine Generate Menu
1. Sine On [117]
2. Sine Burst 1kHz [118]
3. Sine Burst 12kHz [119]
Miscellaneous Menu
1. Clock 11.289 MHz [1400]
2. Clock 12.288 MHz [1401]
3. Clock 24.576 MHz [1402]
4. Colour Setup I2C [1403]
5. Colour Setup High [1404]
6. Colour Setup Low [1405]
7. Colour Setup Normal [1406]
8. Scart Pin Low [1410]
9. Scart Pin Medium [1411]
10. Scart Switch I2C [1407]
11. Scart Switch DVD [1408]
12. Scart Switch Pass [1409]
Front Panel Menu
1. Dim Test [618]
2. Echo [500]
3. Light Labels [503]
4. Led Test [504]
5. Keyboard [506]
6. Remote Control [506]
8. Version [501]
7. Segment Test [502]
Log Menu
1. Application Version Read [406]
2. Error Log Read [404]
3. Error Log Reset [407]
4. Lifetime Log Read [405]
5.4 Nuclei Error Codes
In the following tables the error description of the error codes
will be described.
5.4.1 Host Decoder Nuclei
Error code Error description
10000 Test succeeded.
10001 Test failed, checksum is wrong.
10100 Test succeeded.
10101 FLASH 1 Write access test failed.
10200 Test succeeded.
10201 FLASH 2 Write access test failed.
10300 Test succeeded.
10301 FLASH write test failed.
10302 FLASH write command failed.
10303 FLASH write test done max. number of times.
10400 Memory tests succeeded.
10401 Memory databus test goes wrong at wire dy.
10402 Memory addressbus test goes wrong at wire
ay.
10403 Physical memory device test goes wrong at
address 0xYYYYYYYY.
10500 Memory tests succeeded.
10501 Memory databus test goes wrong at wire dy.
10502 Memory addressbus test goes wrong at wire
ay.
10503 Physical memory device test goes wrong at
address 0xYYYYYYYY.
10600 Memory tests succeeded.
10601 Memory databus test goes wrong at wire dy.
10602 Memory addressbus test goes wrong at wire
ay.
10603 Physical memory device test goes wrong at
address 0xYYYYYYYY.
10700 Memory tests succeeded.
10701 Memory databus test goes wrong at wire dy.
10702 Memory addressbus test goes wrong at wire
ay.
10703 Physical memory device test goes wrong at
address 0xYYYYYYYY.
10800 Test succeeded.
10900 Test succeeded.
10901 Muting audio test failed.
11000 Test succeeded.
11001 Demuting audio test failed.
11100 Test succeeded.
11200 Test succeeded.
11300 Test succeeded.
11400 Test succeeded.
