5.4.7 Miscellaneous Nuclei
5.5 Test instructions SACD mono board
5.5.1 General
Impedance of measuring-equipment should be > 1MΩ
Most tests have to be done by software commands.
Together with the software command you will find a Ref.#
nbr. This is the number of the diagnostic nucleus used for
this test. More detailed information can be found in the
description of the command mode interface.
Levels: Most measurements are digital measurements.
The high and low levels in this document got to have next
specification: low : < 0.3V (LVTTL) high : > 3.0V
(LVTTL) LOW : < 0.4V (TTL) HIGH: > 4.5V (TTL)
All voltages marked with “stby” have to stay on during
standby.
Because all clocks are derived from the SACD clock
(384FS_in) from the DAC board, this board should
always be connected to the mono board.
The linear power supply is switched on/off by the
STB_OUT signal from the mono board to the DAC board.
5.5.2 General start-up measurements
Supply check:
1. Measure the voltages on the pins of the connector 1600
with a multimeter.
2. Also check the following power supplies:
Testpoint F608: +3V3 (5%. (Check IC7605 in case of failure)
Testpoint F632: +3V3 (5%. (Check IC7622 in case of failure)
Testpoint F101: +9V (5%. (Check IC7109 in case of failure)
1. Current at the input of the power supply
Check the supply currents to be sure that there are no major
failures on the board.
Measure the currents flowing toward the mono board using a
Tektronix AM503B current probe on the wires between the
switch mode power supply and the connector 1600.
131300 Test succeeded.
131301 I2C bus busy before start.
131302 I2C access failed.
131400 Test succeeded.
131401 I2C bus busy before start.
131402 I2C access failed.
131500 Test succeeded.
131501 I2C bus busy before start.
131502 I2C access failed.
Error code Error description
140000 Test succeeded.
140001 I2C access failed.
140100 Test succeeded.
140101 I2C access failed.
140200 Test succeeded.
140300 Test succeeded.
140301 I2C bus busy.
140302 I2C device write access time-out.
140303 I2C device no write acknowledge.
140304 I2C device write failed.
140400 Test succeeded.
140401 I2C bus busy before start.
140402 I2C access failed.
140403 Setup of SCART switch failed.
140500 Test succeeded.
140501 I2C bus busy before start.
140502 I2C access failed.
140503 Setup of SCART switch failed.
140600 Test succeeded.
140601 I2C bus busy before start.
140602 I2C access failed.
140603 Setup of SCART switch failed.
140700 Test succeeded.
140701 I2C bus busy.
140702 I2C device read access time-out.
140703 I2C device no read acknowledge.
140704 I2C device read failed.
140800 Test succeeded.
140801 Setup of ColourSetup chip failed.
140802 I2C device write failed.
140900 Test succeeded.
140901 Setup of ColourSetup chip failed.
140902 I2C device write failed.
140903 I2C device read failed.
141000 Test succeeded.
141100 Test succeeded.
Error code Error description
pin TP Signal_name Voltage
1600-1 F604 +3V3 +3V3
1600-2 F604 +3V3 +3V3
1600-3 F631 +5V +5V (0V during standby)
1600-4 F614 +5Vstby +5V
1600-5 F615 +6Vstby +6V
1600-6 F623 GND 0V
1600-7 F623 GND 0V
1600-8 F623 GND 0V
1600-9 F618 -8Vstby -8V
1600-10 F634 STB_CONT 0V (+5V during standby)
1600-11 F636 +12Vstby +12V
1600-12 F623 GND 0V
1600-13 F675 PWR_FAIL +2.1V (1.4V during
standby)
pin TP Signal_name measured
1600-1 F605 +3V3 560 mA
1600-2 F605 +3V3
1600-3 F631 +5V 510 mA
1600-4 F614 +5Vstby 2 mA
1600-5 F615 +6Vstby < 1 mA
1600-6 F623 GND
1600-7 F623 GND
1600-8 F623 GND
1600-9 F618 -8Vstby 54 mA
1600-10 F634 STB_CONT
1600-11 F636 +12Vstby 90 mA
1600-12 F623 GND
1600-13 F675 PWR_FAIL
