Marantz SA12 - Page 151

193
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
MONO-RESISTORS
3906 4822 051 30339 33R00 5% 0.062W QP05130339
3907 2322 704 65609 0603 RC22H 56R PM1 R QH70465609
3908 4822 051 30479 47R00 5% 0.062W QP05130479
3909 4822 051 30332 3k30 5% 0.062W QP05130332
3910 2322 704 65609 0603 RC22H 56R PM1 R QH70465609
4000 4822 051 30008 0R00 JUMPER QP05130008
4004 4822 051 30008 0R00 JUMPER QP05130008
4005 4822 051 30008 0R00 JUMPER QP05130008
4006 4822 051 30008 0R00 JUMPER QP05130008
4452 4822 051 30008 0R00 JUMPER QP05130008
4453 4822 051 30008 0R00 JUMPER QP05130008
4500 4822 051 30008 0R00 JUMPER QP05130008
4503 4822 051 30008 0R00 JUMPER QP05130008
4507 4822 051 30008 0R00 JUMPER QP05130008
4602 4822 051 30008 0R00 JUMPER QP05130008
4603 4822 051 30008 0R00 JUMPER QP05130008
4604 4822 051 30008 0R00 JUMPER QP05130008
4801 4822 051 30008 0R00 JUMPER QP05130008
4802 4822 051 30008 0R00 JUMPER QP05130008
4803 4822 051 30008 0R00 JUMPER QP05130008
4902 4822 051 30008 0R00 JUMPER QP05130008
MONO-SEMICONDUCTORS
6200 4822 130 11397 DIODE BAS316 QP13011397
6301 9322 128 69685 DIODE S1D QA12869685
6302 9322 128 69685 DIODE S1D QA12869685
6303 9322 128 69685 DIODE S1D QA12869685
6600 4822 130 11528 DIODE 1PS76SB10 QP13011528
7000 9337 144 60118 IC SM 74HCT4066D (PHSE) R QN14460118
7001 4822 130 60373 BC856B QP13060373
7002 4822 130 60511 BC847B QP13060511
7003 4822 130 60511 BC847B QP13060511
7006 4822 130 60511 BC847B QP13060511
7007 4822 130 60511 BC847B QP13060511
7100 5322 130 42718 BFS20 QQ13042718
7101 5322 130 42718 BFS20 QQ13042718
7102 9352 637 37518 IC TZA1033HL QB63737518
7103 4822 209 17229 BA5938FM QP20917229
7104 4822 209 30095 IC LM833D QP20930095
7105 4822 209 32073 IC MC34072D QP20932073
7106 5322 130 42718 BFS20 QQ13042718
7107 4822 209 33411 IC MC78L05ACD QP20933411
7108 5322 130 60845 BC807-25 QQ13060845
7109 4822 209 15083 IC AN78M09 QP20915083
7110 5322 130 60803 BST72A QQ13060803
7111 4822 130 60511 BC847B QP13060511
7112 4822 130 60511 BC847B QP13060511
7113 4822 130 60511 BC847B QP13060511
7114 4822 130 60511 BC847B QP13060511
7115 4822 130 60373 BC856B QP13060373
7116 4822 130 60511 BC847B QP13060511
7117 4822 130 42804 BC817-25 QP13042804
7201 9351 869 80118 IC DISPLAY, LCD *D86980118
7202 3104 123 85860 IC AM29F002T/5.1.14 QW12385860
7203 4822 130 60373 BC856B QP13060373
7204 9322 139 67685 IC SM MC33464N-45A QA13967685
7207 4822 209 17231 IC SAA7399HL QP20917231
7304 4822 209 16877 BA6856FP QP20916877
7310 4822 209 15899 IC CY7C199-15C QP20915899
7311 9352 622 13557 IC SAA7335HL QB62213557
7312 4822 130 60373 BC856B QP13060373
7315 4822 130 60511 BC847B QP13060511
7400 9352 499 60118 IC SM 74LVC00AD QB49960118
7402 4822 209 16318 IC MC33464N-30A QP20916318
7404 9322 144 59668 IC SM MT48LC1M16A1TG-7S QA14459668
7405 9322 144 59668 IC SM MT48LC1M16A1TG-7S QA14459668
7452 4822 130 60511 BC847B QP13060511
7453 4822 130 60511 BC847B QP13060511
7454 4822 130 60511 BC847B QP13060511
7455 4822 130 60373 BC856B QP13060373
7503 9322 151 16671 IC STI5505AVC QA15116671
7505 9322 156 81668 IC M24C32-WMN6TNKSA QA15681668
7600 5322 209 71568 IC PC74HCT14T QQ20971568
7604 4822 130 60511 BC847B QP13060511
7605 4822 209 17398 IC LD1117DT33 QP20917398
7607 4822 130 60511 BC847B QP13060511
7608 4822 130 60373 BC856B QP13060373
7609 4822 130 60373 BC856B QP13060373
7610 4822 130 60511 BC847B QP13060511
7611 9352 456 80115 QB45680115
7612 4822 130 60511 BC847B QP13060511
7613 4822 130 60511 BC847B QP13060511
7614 4822 130 60511 BC847B QP13060511
7615 4822 130 60511 BC847B QP13060511
7617 4822 130 60511 BC847B QP13060511
7618 4822 130 60511 BC847B QP13060511
7620 4822 130 60373 BC856B QP13060373
7621 4822 130 42804 BC817-25 QP13042804
7622 4822 209 17398 IC LD1117DT33 QP20917398
7700 9322 144 96668 IC SM MT48LC4M16A2TG-8E QA14496668
7800 9352 680 19557 IC SAA7331HL/M1 QB68019557
7801 5322 130 42718 BFS20 QQ13042718
7900 4822 209 90752 IC 74HCT04D QP20990752
7902 9322 153 36668 IC ICS302M-3 QA15336668
7903 9322 151 72668 IC ICS601M-01T QA15172668
7905 9322 151 71668 IC MK2703STR QA15171668
3104 128 07940 QW12807940
MONO -MISCELLANEOUS
1001 2422 025 16957 FFC CON BM V 24P F 1.00 0.3 QU02516957
1104 2422 025 15963 FFC CON BM H 24P F 0.50 QU02515963
1106 2422 025 16158 FFC CON BM H 8P F 1.00 0.3 QU02516158
1205 2422 540 98428 RES CER 8M467
CSTCC8.46MG
QU54098428
1300 2422 540 98426 RES CER 6MHZ
CSTCC6.00MG
QU54098426
1301 4822 267 51454 CONN. 11P FEMALE QP26751454
1603 2422 025 16389 FFC CON BM V 22P F 1.00 0.3 QU02516389
1604 2422 025 16388 FFC CON BM V 16P F 1.00 0.3 QU02516388
5200 4822 157 11717 BLM31P500SPT QP15711717
5300 4822 157 11717 BLM31P500SPT QP15711717
5301 4822 157 11717 BLM31P500SPT QP15711717
5402 4822 157 11717 BLM31P500SPT QP15711717
5403 4822 157 11499 BLM11P600SPT QP15711499
5450 4822 157 11717 BLM31P500SPT QP15711717
5501 4822 157 70299 2.2µH (NL322522T-2R2J) QP15770299
5502 4822 157 70299 2.2µH (NL322522T-2R2J) QP15770299
5503 4822 157 71206 BLM21A601SPT QP15771206
5504 4822 157 71206 BLM21A601SPT QP15771206
5600 4822 157 71206 BLM21A601SPT QP15771206
5601 4822 157 11499 BLM11P600SPT QP15711499
5602 4822 157 70298 15µH (NL322522T-150J) QP15770298
5604 4822 157 70298 15µH (NL322522T-150J) QP15770298
5605 4822 157 70298 15µH (NL322522T-150J) QP15770298
5606 4822 157 70298 15µH (NL322522T-150J) QP15770298
5607 4822 157 70298 15µH (NL322522T-150J) QP15770298
5608 4822 157 70298 15µH (NL322522T-150J) QP15770298
5609 4822 157 11717 BLM31P500SPT QP15711717
5610 4822 157 11717 BLM31P500SPT QP15711717
5611 4822 157 11717 BLM31P500SPT QP15711717
5700 4822 157 11717 BLM31P500SPT QP15711717
5800 4822 157 11717 BLM31P500SPT QP15711717
5801 4822 157 11717 BLM31P500SPT QP15711717
5802 4822 157 11717 BLM31P500SPT QP15711717
5900 4822 157 11717 BLM31P500SPT QP15711717
5901 4822 157 11717 BLM31P500SPT QP15711717
