202
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
C701 U FILM 1800pF 100V PP APSV OF15182540
C702 4822 121 70437 FILM 1000pF J 100V APSV OF15102540
C703 9965 000 05891 FILM 470pF 100V PP APSV OF15471540
C711 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C711 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C711 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C711 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C712 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C712 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C712 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C712 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C751 F FILM 1800pF 100V PP APSV OF15182540
C751 N 9965 000 10845 FILM 1800pF J 100V NH OF15182550
C751 S 9965 000 10845 FILM 1800pF J 100V NH OF15182550
C751 U FILM 1800pF 100V PP APSV OF15182540
C752 4822 121 70437 FILM 1000pF J 100V APSV OF15102540
C753 9965 000 05891 FILM 470pF 100V PP APSV OF15471540
C761 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C761 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C761 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C761 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C762 F 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
C762 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C762 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
C762 U 4822 124 90051 ELECT. 220µF M 25 V ARA OA22702550
CD01 F 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
CD01 N 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD01 S 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD01 U 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
CD02 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD03 9965 000 05913 CER. 22pF ±2.0% 50V DD942203A0
CD04 9965 000 05913 CER. 22pF ±2.0% 50V DD942203A0
CD05 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD06 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD07 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD08 9965 000 06692 CER. 20pF CH DD95200300
CD09 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD11 4822 122 33753 CER. 150pF ±5% CG 50V GR39 DD95151300
CD12 4822 122 33753 CER. 150pF ±5% CG 50V GR39 DD95151300
CD17 4822 122 33753 CER. 150pF ±5% CG 50V GR39 DD95151300
CD18 4822 122 33753 CER. 150pF ±5% CG 50V GR39 DD95151300
CD21 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD23 F 4822 124 22039 ELECT. 220µF 16V ARA OA22701650
CD23 N 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
CD23 S 4822 124 80123 ELECT. 220µF 16V ARS OA22701640
CD23 U 4822 124 22039 ELECT. 220µF 16V ARA OA22701650
CD24 F 4822 124 22241 ELECT. 47µF 16V ARA OA47601650
CD24 N 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD24 S 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD24 U 4822 124 22241 ELECT. 47µF 16V ARA OA47601650
CD31 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CD32 4822 124 90352 ELECT. 10µF M 16V RA-2 OA10601620
CD33 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CD41 F 9965 000 01318 ELECT. 220µF M 10V RA-2 OA22701020
CD41 N 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD41 S 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD41 U 9965 000 01318 ELECT. 220µF M 10V RA-2 OA22701020
CD42 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD43 F 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
CD43 N 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD43 S 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD43 U 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
CD44 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD45 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD46 F 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
CD46 N 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD46 S 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD46 U 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
CD47 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD48 F 4822 124 22237 ELECT. 10µF 16V ARA OA10601650
CD48 N 4822 124 80543 ELECT. 10µF 35V ARS OA10603540
CD48 S 4822 124 80543 ELECT. 10µF 35V ARS OA10603540
CD48 U 4822 124 22237 ELECT. 10µF 16V ARA OA10601650
CD49 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD51 F 9965 000 01318 ELECT. 220µF M 10V RA-2 OA22701020
CD51 N 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD51 S 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD51 U 9965 000 01318 ELECT. 220µF M 10V RA-2 OA22701020
CD52 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD53 F 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
CD53 N 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD53 S 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD53 U 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
CD54 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD55 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD56 F 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
CD56 N 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD56 S 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD56 U 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
CD57 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD58 F 4822 124 22237 ELECT. 10µF 16V ARA OA10601650
CD58 N 4822 124 80543 ELECT. 10µF 35V ARS OA10603540
CD58 S 4822 124 80543 ELECT. 10µF 35V ARS OA10603540
CD58 U 4822 124 22237 ELECT. 10µF 16V ARA OA10601650
CD59 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD61 F 9965 000 01318 ELECT. 220µF M 10V RA-2 OA22701020
CD61 N 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD61 S 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD61 U 9965 000 01318 ELECT. 220µF M 10V RA-2 OA22701020
CD62 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD63 F 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
CD63 N 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD63 S 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD63 U 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
CD64 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD65 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD66 F 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
CD66 N 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD66 S 4822 124 40433 ELECT. 47µF M 16V ARS OA47601640
CD66 U 9965 000 01567 ELECT. 100µF 10V ARA OA10701050
CD67 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD68 F 4822 124 22237 ELECT. 10µF 16V ARA OA10601650
CD68 N 4822 124 80543 ELECT. 10µF 35V ARS OA10603540
CD68 S 4822 124 80543 ELECT. 10µF 35V ARS OA10603540
CD68 U 4822 124 22237 ELECT. 10µF 16V ARA OA10601650
CD69 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD71 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD72 4822 126 11687 CER. 0.1µF GRM39F104Z16 DK98104200
CD91
CER. 0.01µF DK98103300
CD96
PP16-RESISTORS
R104 4822 051 20121 CHIP 120
Ω ±5% 1/10W NI05121110
R105 4822 051 20121 CHIP 120
Ω ±5% 1/10W NI05121110
R106 4822 117 12521 CHIP 68
Ω ±5% 1/10W NI05680110
R107 4822 051 20228 CHIP 2.2
Ω ±5% 1/10W NI05022110
R108 4822 051 20228 CHIP 2.2
Ω ±5% 1/10W NI05022110
R109 4822 117 12367 CHIP 33k
Ω ±1% 1/10W NI01333110
R110 4822 051 20102 CHIP 1k
Ω ±5% 1/10W NI05102110
R111 4822 051 20102 CHIP 1k
Ω ±5% 1/10W NI05102110
R112 4822 051 20101 CHIP 100
Ω ±5% 1/10W NI05101110
R154 4822 051 20121 CHIP 120
Ω ±5% 1/10W NI05121110
R155 4822 051 20121 CHIP 120
Ω ±5% 1/10W NI05121110
R156 4822 117 12521 CHIP 68
Ω ±5% 1/10W NI05680110
R157 4822 051 20228 CHIP 2.2
Ω ±5% 1/10W NI05022110
R158 4822 051 20228 CHIP 2.2
Ω ±5% 1/10W NI05022110
