133
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
002B F FRONT PANEL GOLD HAIR 413K248120
002B N, S 9965 000 10828 FRONT PANEL GOLD BLAST 413K248110
002B U FRONT PANEL BLACK BLAST 413K248010
003B GOLD 9965 000 10825 ESCUTCHEON
SIDE CORNER GOLD
413K063110
003B BLACK ESCUTCHEON
SIDE CORNER BLACK
413K063010
005B 4822 381 11893 LENS FOR LED 269J355010
006B 9965 000 10823 LENS FOR STANDBY 230K355010
008B GOLD 9965 000 01554 MARANTZ BADGE GOLD 313J251110
008B BLACK 9965 000 01553 MARANTZ BADGE BLACK 313J251010
010B GOLD 9965 000 10829 FRONT PANEL
SUB PANEL AL GL
413K248130
010B BLACK FRONT PANEL
SUB PANEL AL BL
413K248030
020B GOLD 9965 000 10832 BUSHING PLAY BUTTON GL 413K259110
020B BLACK BUSHING BUTTON BL 413K259010
024B GOLD 9965 000 10835 BUTTON PLAY GL 413K270110
024B BLACK BUTTON PLAY BL 413K270010
026B GOLD BUSHING
NEXT/PREV. BUTTON GL
413K259130
026B BLACK BUSHING
NEXT/PREV. BUTTON BL
413K259030
028B GOLD 9965 000 10837 BUTTON NEXT/PREV.GL 413K270130
028B BLACK BUTTON NEXT/PREV.BL 413K270030
030B 9965 000 06862 ESCUTCHEON (SACD LOGO) 392K063160
034B GOLD 9965 000 10833 BUSHING
OPEN/CLOSE BUTTON GL
413K259120
034B BLACK BUSHING
OPEN/CLOSE BUTTON BL
413K259020
038B GOLD 9965 000 10836 BUTTON OPEN/CLOSE GL 413K270120
038B BLACK BUTTON OPEN/CLOSE BL 413K270020
040B GOLD 9965 000 10834 BUSHING POWER GL 413K259140
040B BLACK BUSHING POWER BL 413K259040
044B GOLD 4822 410 11276 BUTTON POWER GL 176J270150
044B BLACK 4822 410 11275 BUTTON POWER BL 176J270050
046B GOLD 9965 000 10826 TRAY ESCUTCHEON GL 413K063120
046B BLACK TRAY ESCUTCHEON BL 413K063020
076B GOLD 9965 000 10827 WINDOW FOR GL 413K158110
076B BLACK WINDOW FOR BL 413K158010
001D GOLD 9965 000 10831 TOP LID GOLD 413K257110
001D BLACK TOP LID BLACK 413K257010
005D GOLD 4822 502 14462 SCR.THINHEAD 3X5NI 318K010020
005D BLACK 4822 502 14461 SCR.THINHEAD 3X4BL 318K010030
006D GOLD 9965 000 10830 SIDE PANEL GOLD 413K249110
006D BLACK SIDE PANEL BLACK 413K249010
009D GOLD 4822 502 14425 SCR.THINHED 3X8NI 323S010020
009D BLACK 4822 502 21693 SCR.THINHED 3X7BL 323S010030
010D INSULATOR FOR TOP LID 256J120010
004G 4822 462 11116 LEG GOLD BLAST 163J057410
005G 9965 000 10824 SCREW FOR LEG 413K010010
001M 9305 023 61104 VAL6011/04
LOADER COMPLETE
QE02361104
022M 3104 126 25210 DUST CAP QW12625210
J603 9965 000 10849 TERMINAL EW-2560T-LH-W
L-CH
YT02011290
J613 9965 000 10848 TERMINAL EW-2560T-LH-R
R-CH
YT02011280
J623 9965 000 10849 TERMINAL EW-2560T-LH-W
LS-CH
YT02011290
J633 9965 000 10848 TERMINAL EW-2560T-LH-R
RS-CH
YT02011280
J643 9965 000 10850 TERMINAL EW-2560T-LH-B
C-CH
YT02011300
J653 9965 000 10850 TERMINAL EW-2560T-LH-B
LEE-CH
YT02011300
L001 F MAINS TRANSF. 100V 50/60Hz TS58001020
L001 N, S, U 3104 128 70230 MAINS TRANSF. 115/230V TS58001010
L011 9965 000 10839 FERRITE CORE
TRCN-16-8-13 FOR JH05-SPSU
FC50160040
L012 9965 000 10840 FERRITE CORE
USB-4 FOR L001PRI.
FC50270040
L013 4822 526 10691 FERRITE CORE
TFCK-16-8-13 FOR L001 SEC.
FC50160030
L014 4822 526 10691 FERRITE CORE
TFCK-1608013 CN202 MONO
FC50160030
L015 9965 000 06824 FERRITE CORE
HF70SH28X2X10 FOR FFC
FC90280010
L016 4822 526 10691 FERRITE CORE
TFCK16-8-13 FOR WY04
FC50160030
PZ03 3104 129 22150 POWER SUPPLY UNIT QW12922150
0025 8204 056 06810 FUSE 2A GMD-2
FOR POWER SUPPLY UNIT
QC05606810
PACKING
001T F USER GUIDE 413K851110
001T N 9965 000 10838
USER GUIDE
413K851310
001T S
USER GUIDE
413K851350
001T U
USER GUIDE
413K851250
T100 9965 000 10851 REMOTE CONTROLLER
RC-12S1SA
ZK413K0010
W001 F 4822 321 11337 MAINS CORD
MITY DC-302-J 125V 12A
ZC01802080
W001 N 4822 321 11033 MAINS CORD
2P 10A 250V CLASS2
ZC01803080
W001 S MAINS CORD
250V 10A FOR UK
ZC01804100
W001 U MAINS CORD
10A 125V UL/CSA
ZC01803100
NOT STANDARD
SPEAR PARTS
001S PACKING CASE 413K801010
002S CUSHION 413K809010
008S ACCESSORY BOX 413K801210
