122 Appendix B: Technical information
Matrox Solios eA (starting from version 100)/Matrox Solios XA (starting from version 200)
Operating voltage
and current (XA)
1
Matrox Solios XA Single Matrox Solios XA Dual Matrox Solios XA Quad
Typical: 5.0 V, 1.46 A = 7.3 W
Typical: 12 V, 0.081 A = 0.975 W
Total (typical) = 8.275 W
Typical: 5.0 V, 1.552 A = 7.76 W
Typical: 12 V, 0.203 A = 2.44 W
Total (typical) = 10.20 W
Typical: 5.0 V, 1.64 A = 8.21 W
Typical: 12 V, 0.325 A = 3.90 W
Total (typical) = 12.11 W
Operating voltage
and current (eA)
Matrox Solios eA Single Matrox Solios eA Dual Matrox Solios eA Quad
Typical: 3.3 V, 1.58 A = 5.21 W
Typical: 12V, 0.27 A = 3.19 W
Total (typical) = 8.40 W
Typical: 3.3 V, 2.05 A = 6.76 W
Typical: 12 V, 0.354 A = 4.25 W
Total (typical) = 11.01 W
Typical: 3.3 V, 2.52 A = 8.31 W
Typical: 12V, 0.44 A = 5.30 W
Total (typical) =13.61 W
Analog data signal
specification
75 Ohm termination.
Peak signal without saturation: 2.4 V.
Clamped to -5 V and to 5 V (max source current +0.5 A).
Amplitude:
• 0.25 V (min) to 1.2 V (max) (terminated) if using a maximum gain factor of 4.
• 0.5 V (min) to 2.4 V (max) (terminated) if using a maximum gain factor of 2.
I/O Specifications
Input signals in
LVDS format
110 Ohm differential termination.
On the analog video input (DVI) connectors:
• Input current: -10 μA (min) to +10 μA (max).
•Input voltage:
- common-mode voltage: 0.1 V (min) to 2.3 V (max).
- differential threshold: low of -100 mV (min); high of 100 mV (max).
On external auxiliary I/O connector 0:
• Differential input current: -1.8 mA (min) to +1.8 mA (max).
•Input voltage:
- common-mode: -0.5 V (min) to 5 V (max).
- differential threshold: low of -200 mV (min); high of 200 mV (max).
Output signals in
LVDS format
On the analog video input (DVI) connectors:
• No termination.
• Output current (loaded 100 Ohm): 3.1 mA (typ).
• Output voltage (loaded 100 Ohm):
- differential: 250 mV (min) to 450 mV (max).
- common-mode: 1.125 V (min) to 1.375 V (max).
- low of 1.02 V (typ), 0.9 V (min); high of 1.33 V (typ), 1.6 V (max).
On external auxiliary I/O connector 0:
• Output current (loaded 100 Ohm): 26 mA total (typ).
• Output voltage (loaded 100 Ohm):
- differential: 250 mV (min), 450 mV (max).
- common-mode: 1.125 V (min), 1.375 V (max).
