Connectors on Matrox Solios eCL/XCL-B 129
To build your own cable, you can purchase the following parts:
These parts can be purchased from third parties such as Digi-Key Corporation
(www.digikey.com).
4 8 P0_LVDS_AUX_IN0+ LVDS auxiliary input 0 (positive).
Supported signals: trigger input 0, field input, user-defined input 5, or quadrature input bit 0.
5 3 P0_LVDS_AUX_IN0- LVDS auxiliary input 0 (negative).
See pin 4 for more information.
6 - P0_LVDS_AUX_IN1+ LVDS auxiliary input 1 (positive).
Supported signals: trigger input 1, timer clock input 0, user-defined input 6, or quadrature input
bit 1.
76GND Ground.
8. - P0_LVDS_AUX_IN1- LVDS auxiliary input 1 (negative).
See pin 6 for more information.
9 2 P0_OPTO_AUX_IN0- Opto-isolated auxiliary input 0 (negative).
See pin 15 for more information.
10 - GND Ground.
11 5 P0_OPTO_AUX_IN1- Opto-isolated auxiliary input 1 (negative).
See pin 12 for more information.
12 4 P0_OPTO_AUX_IN1+ Opto-isolated auxiliary input 1 (positive).
Supported signals: trigger input 1, or user-defined input 1.
13 - P0_LVDS_AUX_OUT0+ LVDS auxiliary output (positive).
Supported signals: exposure output 0 or user-defined output 5.
14 - P0_LVDS_AUX_OUT0- LVDS auxiliary output (negative).
See pin 13 for more information.
15 7 P0_OPTO_AUX_IN0+ Opto-isolated auxiliary input 0 (positive).
Supported signals: trigger input 0, field input, user-defined input 0.
- 9 NC Not connected.
Pinout
for
DB-15
Pinout
for
DB-9
Signal Description
Mating information for DB-15 Mating information for DB-9
Manufacturer: NorComp, Inc. NorComp, Inc.
Connector: 180-044-102-001 172-E09-102-031
Backshell: 970-025-010-011 970-009-010-011
