Connectors on Matrox Solios eA/XA 143
6 P1_TTL_AUX(EXP)_OUT TTL auxiliary output for acq.
path 1.
Supported signals: exposure
output 0 (main purpose) or
user-defined output 2.
22 P1_TTL_AUX(TRIG)_IN TTL auxiliary input for acq.
path 1.
Supported signals: trigger input
0 (main purpose), field input, or
user-defined input 0.
7 P1_RS232_RxD RS-232 serial input to acq.
path 1 of frame grabber
(UART).
23 P0_TTL_AUX(EXP)_OUT TTL auxiliary output for acq.
path 0.
Supported signals: exposure
output 0 (main purpose) or
user-defined output 2.
8 P1_RS232_TxD RS-232 serial output from acq.
path 1 (UART) to video source.
24 P0_RS232_RxD RS-232 serial input to acq. path
0 of frame grabber (UART).
9 P1_LVDS/TTL_CHSYNC_IO- CSYNC input or HSYNC
input/output for acq. path 1
(negative).
C1 P0_VID_IN_A Video input A for acq. path 0
(AC/DC).
10 P1_LVDS/TTL_CHSYNC_IO+ CSYNC input or HSYNC
input/output for acq. path 1
(positive).
C2 P1_VID_IN_A Video input A for acq. path 1
(AC/DC).
11 GND Ground. C3 P2_VID_IN_A Video input A for acq. path 2
(AC/DC).
12 P0_LVDS/TTL_CHSYNC_IO- CSYNC input or HSYNC
input/output for acq. path 0
(negative).
C4 P3_VID_IN_A Video input A for acq. path 3
(AC/DC).
13 P0_LVDS/TTL_CHSYNC_IO+ CSYNC input or HSYNC
input/output for acq. path 0
(positive).
C5 GND Ground.
14 P0_TTL_AUX(TRIG)_IN TTL auxiliary input for acq.
path 0.
Supported signals: trigger input
0 (main purpose), field input,
or user-defined input 0.
C6 GND Ground.
15 GND Ground. M1 GND Ground.
16 P0_RS232_TxD RS-232 serial output from acq.
path 0 (UART) to video source.
M2 GND Ground.
1. Note that only signals defined for acquisition path 0 (those that begin with P0) and the grounds (GND) apply to the Matrox Solios eA/XA Single board. Only signals
defined for acquisition paths 0 and 1 (P0 and P1) and the grounds (GND) apply to the Matrox Soilios eA/XA Dual.
Pin
Signal
1
Description Pin
Signal
1
Description
