66 Chapter 4: Matrox Solios hardware reference
Matrox Solios eCL/XCL-B has auxiliary/camera control signals in the following
formats:
Matrox Solios eCL/XCL dual-Base/single-Medium in dual-Base mode has
auxiliary/camera control signals in the following formats:
Matrox Solios eCL/XCL dual-Base/single-Medium in single-Medium mode and
Matrox Solios eCL/XCL-F have auxiliary/camera control signals in the following
formats:
Note that the opto-isolated signals pass through an opto-coupler, a device that
protects the board from outside surges and different ground levels, and allows the
frame grabber to be totally isolated.
Auxiliary signals
# total
1
1. This is the number of auxiliary signals available when using the DB-15 auxiliary I/O connector; if replaced with the optional
DB-9 connector from the SOLCLBACCxxPAK accessory kit, less auxiliary signals are available (see the pinout of the auxiliary
I/O connector in Appendix B: Technical information).
LVDS camera control output signals. 4
TTL auxiliary input or output signals. 3
Opto-isolated auxiliary input signals. 2
LVDS auxiliary input signals. 2
LVDS auxiliary output signals. 1
Auxiliary signals # per path # total
LVDS camera control output signals. 4 8
TTL auxiliary input or output signals. 2 (+2 depending on type of signal) 6
Opto-isolated auxiliary input signals. depends on type (2 reserved for P0, 2 not specified) 4
LVDS auxiliary input signals. depends on type (2 reserved for P0, 2 not specified) 4
LVDS auxiliary output signals. 2 4
Auxiliary signals # total
LVDS camera control output signals. 4
TTL auxiliary input or output signals. 4
Opto-isolated auxiliary input signals. 4
LVDS auxiliary input signals. 4
LVDS auxiliary output signals. 2
