Record functionality
Remarks
• The green LED indicates that a valid sources is connected; however, if a
source is disabled during a Multi-cam session, the green LED will replace
the pulsing red LED.
• The red LED pulses when the source is recording.
• If dropped or skipped frames are detected during a source recording, the
Record Status LED corresponding to the source turns yellow while the
dropped/skipped frames are occurring. The dropped/skipped events for each
source recording are logged in the record log file for the recording session
(see “Record log file” on page 28).
• The status LED will briefly turn blue when an event marker has been created
(see “Event markers” on page 29).
Dropped-Frame indicator
If dropped or skipped frames are detected during a recording session, a
Dropped-Frame indicator appears and remains visible until a new recording
session is initiated. In Multi-Cam mode, the Dropped-Frame indicator appears on
the Control bar (see “Control bar” on page 17) to indicate that at least one of the
source recordings experienced dropped/skipped frames. In Independent mode,
dedicated Dropped-Frame indicators appear in the source window (see “Source
window popover” on page 20) corresponding to the source recording that
experienced the dropped/skipped frames.
Red LED (pulsing)
Source is recording
without incident
Green LED (on)
Source is connected
and enabled
Yellow LED (pulsi ng)
Recording currently experiencing
dropped/skipped frames
Blue LED (pulses briefly)
An event marker has
been created
Multi-Cam mode
(on Control bar)
Independent mode
(in source window popover)
