Upgrading The Computer
Upgrading the Hard Disk Drive 6 - 9
6
4. Press down on the rubber case to ensure the assembly is properly seated
before replacing the cover and screws.
5. Replace the component bay cover (see “Removing/Replacing the Component
Bay Cover” on page 6 - 4).
Figure 6 - 8
Seat the Assembly
2
2
2
