Setup
Connections
EPOS4 50/5 Hardware Reference
CCMC | 2023-07 | rel11726
3-41
Table 3-39 Digital output specification
Figure 3-29 DigOUT1 circuit (analogously valid for DigOUT2)
Continued on next page.
Digital outputs 1…2
Circuit
Open drain (internal pull-up resistor 2k2 and diode
to +5.45 VDC
