McCrometer ProComm - Menu Structure

MAIN MENU
1-Sensor
2-Units
3-Scales
4-Measure
5-Alarms
6-Inputs
7-Outputs
8-Communication
9-Display
10-Data logger
11-Functions
12-Diagnostic
13-System
4.4 Menu Structure
The following is the menu structure for the ProComm converter. NOTE: Some menus change as options are enabled.
1-SENSOR
1.1 S.model= 000
1.2 Lining= UNSPEC.
1.3 S.type= INSER.
1.4 U.type= METRIC
1.5 Diam.=mm
1.6 KA=
1.7 KZ=
1.8 KD=
1.9 Ins.position=
1.10 KP dynamic=
1.11 Ki=
1.12 Kp=
1.13 KC=
1.14 C.Curr.=mA
1.15 C.Reg.PB=
1.16 C.Reg.DK=
1.17 S.Freq.=Hz
1.18 E.P.Detect=
1.19 R max=kohm
1.20 El.cleaning
1.21 S.cable=ft
1.22 S.err.delay=
1.23 Sens.verify=
1.24 KL=00
2-UNITS
2.1 Diam.= mm
2.2 S.cable= m
2.3 FR.unit= METRIC
2.4 P11 unit= METRIC
2.5 P12 unit= METRIC
2.6 T+ unit= METRIC
2.7 T+ unit= dm
3
2.8 T+ D.P.= x
2.9 Temp.unit= METRIC
2.10 Mass unit= ON
7-OUTPUTS
7.1 Out1=PULSES+
7.2 Out2=PULSES-
7.3 Out mA1=4_22+/-
7.4 Out mA2=4_22+/-
7.5 A1S=l/s 4.9087
7.6 A2S=l/s 4.9087
4-MEASURE
4.1 Damping=SMART
4.2 Cutoff=%00.1
4.3 Cal.verify=ON
4.4 Autorange=ON
4.5 H.imm.inp.=
5-ALARMS
5.1 Max+=dm3/s
5.2 Max-=dm3/s
5.3 Min+=dm3/s
5.4 Min-=dm3/s
5.5 Hysteresis=%03
5.6 mA v.alarm=%000
6-INPUTS
6.1 T+ reset=OFF
6.2 P+ reset=OFF
6.3 T- reset=OFF
6.4 P- reset=OFF
6.5 Count lock=OFF
6.6 Meas.lock=OFF
6.7 Calibration=OFF
6.8 Range change=OFF
9-DISPLAY
9.1 Language=EN
9.2 Contrast=5
9.3 Disp.time=s020
9.4 D.rate=Hz5
9.5 Disp.fn=1
9.6 Disp.lock=ON
9.7 Part.tot.=
9.8 Neg.tot.=ON
9.9 Quick start=ON
11-FUNCTIONS
11.1 T+ reset
11.2 P+ reset
11.3 T- reset
11.4 P- reset
11.5 Load Sens.f.def
11.6 Load Conv.f.def
12-DIAGNOSTIC
12.1 Self test=
12.2 Display data=
12.3 Sens.verify
12.4 Flow sim.=ON
12.5 Firmware info
12.6 S/N=999001
12.7 WT=0002:21:00:22
13-SYSTEM
13.1 L1 code= ********
13.2 L2 code= ********
13.3 L3 code= ********
13.4 L4 code= ********
13.5 010.011.012.013
13.6 010.011.012.014
13.7 255.255.255.000
13.8 FW update
3-SCALES
3.1 FS1=
3.2 Pls1=
3.3 Tpls1=
3.4 Pls2=
3.5 Tpls2=
8-COMMUNICATION
See section 5.8 for a full
description of this menu.
10-DATA LOGGER
10.1 D.logger en= OFF
10.2 Meas. units= ON
10.3 Field separ.= ;
10.4 Interv.=xx:xx:xx
10.5 Log T+=ON
10.6 Log P+=ON
10.7 Log T-=ON
10.8 Log P-=ON
10.9 Log TN=ON
10.10 Log PN=ON
10.11 Log Q(UM)=ON
10.12 Log Q(%)=ON
10.13 Log AL.EV=ON
10.14 Log STR=ON
10.15 Log BTS=ON
10.16 Log IBV=ON
10.17 Log EDC=ON
10.18 Log AEC=ON
10.19 Log EIZ=ON
10.20 Log SCV=ON
30124-60 Rev. 1.0 | unreleased
Page 15
CONVERTER OPERATION
ProComm
Preliminary
