McCrometer ProComm - Menu 8 - Communication

Menu
Position
Converter Function Code Function Name Function Description
Access
Level
MCP
Command
7.5
[A1S=dm3/s
4.9087]
Analog Output1
full scale
Sets the full scale value for analog
output 1 independently of the
main scale of the instrument
AL3 [AO1FS]
7.6
[A2S=dm3/s
4.9087]
Analog Output2
full scale
Sets the full scale value for analog
output 1 independently of the
main scale of the instrument
AL3 [AO2FS]
5.8 Menu 8 - Communication
The Communication menu will populate with commands that are specic to the output mode or protocol that the converter
is congured to. The menus shown below are for Hart, MODBUS, and AMR.
HART
Menu
Position
Converter Function Code Function Name Function Description
Access
Level
MCP
Command
8.1 [HART pr.=XXXXXX] Hart Preamble Number of preamble (Hart
function)
AL3 [HARTP]
8.2 [HART o.c.=XXXXXX] AL3
8.3 [HART nd d=XXXXXX] AL3
8.4 [HART w.p.=XXXXXX] AL3
8.5 [Dev. Addr=XXXXXX] Device Address AL3 [DVADD]
MODBUS
Menu
Position
Converter Function Code Function Name Function Description
Access
Level
MCP
Command
8.1
[Dev. Addr=XXXXXX]
Device Address AL3 [DVADD]
8.2
[Speed=bps9600]
Speed AL3
8.3
Parity=no
Parity AL3
8.4
Delay=ms00
Delay AL3
8.5
[C.timeout=2]
Time Out AL3 [DVADD]
AMR
Menu
Position
Converter Function Code Function Name Function Description
Access
Level
MCP
Command
8.1
T.RD.p.t=MIM087
(Sensus)
AL3
8.2
MIM086 (Itron 6)
8.3
MIM085 (Itron 9)
30124-60 Rev. 1.0 | unreleased
Page 31
Menu Descriptions
ProComm
Preliminary
