5.7 Menu 7 - Outputs
Menu
Position
Converter Function Code Function Name Function Description
Access
Level
MCP
Command
7.1
[Out1=PULSES+]
Output 1
function
selection
Sets the selection for Output 1.
The functions are listed in the
table below.
AL3 [OUT1F]
7.2
[Out2=PULSES-]
Output 2
function
selection
Sets the selection for Output 2.
The functions are listed in the
table below.
AL3 [OUT2F]
FUNCTIONS FOR OUTPUTS 1 AND 2
OFF: DISABLE
MAX AL. +: MAX DIRECT FLOW RATE OUTPUT (ENERGIZED = AL. OFF)
MIN AL. +: MIN DIRECT FLOW RATE OUTPUT (ENERGIZED = AL. OFF)
MAX AL.-: MAX INVERSE FLOW RATE OUTPUT (ENERGIZED = AL. OFF)
MIN AL.-: MIN INVERSE FLOW RATE OUTPUT (ENERGIZED = AL. OFF)
MAX/MIN-: MAX/MIN INVERSE FLOW RATE OUTPUT (ENERGIZED = AL. OFF)
MAX/MIN+/-: MAX/MIN DIRECT FLOW RATE OUTPUT (ENERGIZED = AL. OFF)
P.EMPTY: EMPTY PIPE ALLARM OUTPUT (ENERGIZED = AL. OFF)
AL.SYSTEM: SUM OF ALL ALARMS ”energized interrupted ” AND ”error input signal ”
OVERFLOW: OUT OF RANGE ALLARM OUTPUT (ENERGIZED = FLOWRATE OK)
ALL ALARMS: SUM OF ALL ALARMS POSSIBLE
MANUAL: OUTPUT MAY TAKE A STATE EMPLOYEE FROM AN EXTERNAL CONTROL (MCP, MODBUS, etc.)
FLOW DIR.: FLOW DIRECTION (EXCLUDED WHEN THE FLOW IS NEGATIVE)
SCALE: INDICATION SCALE
FREQ.+: FREQUENCY POSITIVE FLOWRATE
FREQ.-: FREQUENCY NEGATIVE FLOWRATE
FREQ.+/-: FREQUENCY POSITIVE/NEGATIVE FLOWRATE
IMPULSI+: PULSE POSITIVE FLOW RATE
IMPULSI-: PULSE NEGATIVE FLOW RATE
IMPULSI+/-: PULSE NEGATIVE/POSITIVE FLOW RATE
7.3
[Out mA1=4_22+/-]
Current output
option and range
Sets the current Output 1. AL3 [OUT1F]
30124-60 Rev. 1.0 | unreleased
Page 29
