Menu
Position
Converter Function Code
Function
Name
Function Description
Access
Level
MCP
Command
3.2
[Pls1=g1000.00]
Output Pulse
1
Pls1 is active with POS.7.1. This
enables and sets the pulse value on
channel 1. This function allows the
user to set a signal (a pulse) to be
given from the converter when a
dened amount of liquid has passed
through the sensor.
AL2 [OP1PV]
To set the parameter, complete the two elds, from left to right: 1)measure unit, 2) numeric value. To
change the unit type (metric, Imperial, mass or volume), see POS.2.4-2.5 and POS.2.19-2.20. The value of
Pls1 depends on nominal diameter POS.1.4. Only those units described (POS.3.1-3.2) above are available for
selection.
NOTE: Since the converter can not detect which two problems may occur, rst, if the pulse is too long, the
coils may burn out, and second, if the pulse is too short, the counter may not be able to function due to the
possibility of causing damage of the output.
3.3
[Tpls1=ms0050.0]
Output Pulse
1 time
Tpls1 is active with POS.7.1 is
enabled. This sets the duration of the
pulse generated on channel, with the
liquid volume to generate the pulse
value (POS.3.3-3.5) set by the user.
AL2 [OP1PT]
The user must set the corresponding duration of the pulse for output. This value is expressed in
milliseconds and has to be between 0.4 and 9999.99.
3.4
[Pls2=g1000.00]
Output Pulse
2
See menu 3.2, Output Pulse 1 AL2 [OP2PV]
3.5
[Tpls2=ms0050.0]
Output Pulse
2 Time
See menu 3.3, Output Pulse 1 Time AL2 [OP2PT]
30124-60 Rev. 1.0 | unreleased
Page 23
