31Service manual for medifa 6000 mobile operating tables, version 2.0
Components column / top frame
After the valve block [2] has been completely disassembled, the new valve block can be connected according to the hydraulic
diagram and your documentation. Afterwards, the two forked photoelectric sensors can be mounted and the valve block
can be screwed to the provided holder. It is important that the fork photoelectric sensors are mounted on the same block
where they were before. If the fork photoelectric sensors are interchanged, the adjustment function of the table is severely
impaired!
Now connect the power supply to the two adjustment motors of the rotary valve and bring the two protective tubes above
them into position.
WARNING
Ensure that the motors are polarised correctly, otherwise they will turn in the wrong direction. This could severely impair the
respective adjustment function of the table!
