34 Service manual for medifa 6000 mobile operating tables, version 2.0
Components of base
To take out the control unit, it only needs to be lifted to
release the Velcro. Then pull the control unit out of the
base.
The assembly is carried out in the reverse order. Please
note that after the installation of the new control unit,
the calibration programme must be carried out (see
chapter Calibration).
The cable assignment can be found in your
documentation and the cable diagram.
Figure 52
