59Service manual for medifa 6000 mobile operating tables, version 2.0
Hydraulic diagram
Item No. Hose connections Length
600 01 Pipe socket. ø3 -- Pipe socket Ø3 90° HMF
600 02 Pipe socket ø3 -- Pipe socket Ø3 HMF
600 03 Pipe socket ø3 -- Pipe socket Ø3 HMF
600 04 Screwed ring joint M8x1 -- pipe socket Ø3 90° HMF
600 05 Screwed ring joint M8x1 -- pipe socket Ø3 90° HMF
600 06 Screwed ring joint M8x1 -- pipe socket Ø3 90° HMF
600 07 Screwed ring joint M8x1 -- pipe socket Ø3 90° HMF
600 08 Screwed ring joint M8x1 -- pipe socket Ø3 90° HMF
600 09 Screwed ring joint M8x1 -- pipe socket Ø3 90° HMF
600 10 Pipe socket ø3 90° -- Plug-in coupling W 120 mm
600 11 Pipe socket ø3 90° -- Plug-in coupling M 120 mm
600 12 Pipe socket ø3 90° -- Screwed ring joint M8x1 450 mm
600 13 Pipe socket ø3 90° -- Screwed ring joint M8x1 550 mm
600 14 Pipe socket ø3 90° -- Plug-in coupling W 120 mm
600 15 Pipe socket ø3 90° -- Plug-in coupling M 120 mm
120 01 Plug-in coupling M -- Screwed ring joint M8x1 1200 mm
120 02 Plug-in coupling W -- Screwed ring joint M8x1 1200 mm
820 03 Plug-in coupling M -- Screwed ring joint M8x1 500 mm
820 04 Plug-in coupling W -- Screwed ring joint M8x1 550 mm
820 05 Plug-in coupling M -- Screwed ring joint M8x1 850 mm
820 06 Plug-in coupling M -- Screwed ring joint M8x1 1000 mm
820 07 Plug-in coupling M -- Screwed ring joint M8x1 900 mm
820 08 Plug-in coupling M -- Screwed ring joint M8x1 1050 mm
820 09 Plug-in coupling M -- Screwed ring joint M8x1 550 mm
820 10 Plug-in coupling M -- Screwed ring joint M8x1 550 mm
820 11 Plug-in coupling M -- Screwed ring joint M8x1 750 mm
820 12 Plug-in coupling M -- Screwed ring joint M8x1 750 mm
